6-layer CM3588 carrier board

A 6-layer, high-speed carrier board built around the CM3588 module, integrating USB 3.0, four MIPI camera interfaces, WiFi/Bluetooth connectivity, ultra-wideband connectivity (UWB), an IMU, and battery power management in a single compact design.

Our contribution

• Schematic design, PCB layout & routing

Status: Design complete, PCB manufactured

Key features

• Six-layer PCB
• CM3588 module
• USB 3.0
• Four MIPI camera interfaces
• BQ24179-based battery power management
• AP6256 Wi-Fi and Bluetooth
• BMI270 IMU
• DWM1000 ultra-wideband transceiver
